The FDO 70x IQ The FDO 70x IQ sensor is a dissolved oxygen measuring device that uses optical measurement technology, manufactured by WTW (a Xylem brand).
In Vietnam, with the rapid development of industrialization and urbanization, the demand for water quality monitoring is increasing. With its corrosion resistance and minimal calibration requirements, the FDO 70x IQ is an ideal choice for industries such as wastewater treatment, aquaculture, and environmental monitoring.
Dissolved Oxygen (DO) is an important parameter that directly affects the survival of aquatic organisms and the efficiency of water treatment processes.
Key Features of the FDO 70x IQ
The FDO 70x IQ sensor offers a range of superior features, making it stand out compared to competing products on the market:
- Minimal calibration The device is factory calibrated before shipping.
- Independent of flow rate Suitable for environments with unstable flow conditions, such as wastewater or fish farming ponds.
- Insensitive to air bubbles The 45° sensor membrane angle minimizes the impact of air bubbles.
- Corrosion-resistant All components in contact with water are made of titanium and plastic, optimized for seawater, river water, or environments with high salinity.
- Durable design: It can operate at pressures up to 10 bar, making it suitable for heavy industrial applications.
Models and Technical Specifications of FDO 70x IQ
The FDO 70x IQ sensor includes the following models:
FDO® 700 IQApplications in biological treatment processes.
FDO® 701 IQIt has a faster response time, making it suitable for applications that require quick response.
FDO® 700 IQ SW và FDO® 701 IQ SWA specialized version for seawater, optimized for environments such as desalination plants, brackish water, aquaculture, or areas with high salinity. The components in contact with water are made of titanium and plastic, ensuring superior corrosion resistance.
FDO 70x IQ Technical Specifications
The FDO 70x IQ sensor includes two main models: FDO 700 IQ SW and FDO 701 IQ SW, with the technical specifications presented in the table below:
| Parameter | FDO 700 IQ SW | FDO 701 IQ SW |
| Measurement methods | Optical | Optical |
| Measuring Range (25°C) | O₂: 0…20.00 mg/l, Saturation: 0…200% | O₂: 0…20.00 mg/l, Saturation: 0…200% |
| Accurary | 1 mg/l: ±0.1 mg/l | 1 mg/l: ±0.1 mg/l |
| Response Time (25°C) | t90: <150s, t95: <200s | t90: <60s, t95: <80s |
| Operating temperature | -5°C…+50°C | -5°C…+40°C |
| Maximum Pressure | 10 bar | 10 bar |
| Materials in Contact with Water | Titanium and plastic, corrosion-resistant | Titanium and plastic, corrosion-resistant |
| Sensor Membrane Lifespan | 2 years | 6 months |
How is the FDO 70x IQ applied?
The FDO 70x IQ sensor is optimized for the following applications:
- Wastewater Treatment Helps monitor and control the aeration process in activated sludge systems, optimizing oxygen levels for biological treatment, thereby reducing energy costs.
- Aquaculture Maintains optimal oxygen levels for fish and aquatic organisms, especially in large aquaculture areas such as the Mekong Delta, where seawater and brackish water dominate.
- Environmental Monitoring Evaluates water quality in rivers, lakes, and oceans. Supports environmental regulatory bodies in implementing effective water resource protection measures.
Benefits of Using
Using the FDO 70x IQ sensor offers several practical benefits:
- Reduce operating costs With minimal calibration requirements and the long lifespan of the sensor membrane, businesses can save on maintenance and replacement costs.
- Accurate and reliable measurement With high accuracy and compliance with international standards, the device ensures reliable data, supporting effective management and operations.
- Easy Integration: Can be connected to the IQ Sensor Net system for remote monitoring and data management, aligning with the digitalization trend in management.
Why choose Viet An Enviro?
Viet An Enviro is the distributor of the FDO 70x IQ SW sensor in Vietnam, offering comprehensive solutions from consultation to installation. With over 1,500 monitoring stations implemented, we are committed to delivering quality products and dedicated services.
