In the context of automated emissions monitoring systems in Vietnam, the VCEM 5000/5100 flue gas flow measurement device from CODEL (United Kingdom), distributed by Viet An Enviro, is an optimal solution for industrial plants. This product utilizes advanced infrared flow measurement technology, delivering high efficiency in monitoring industrial emissions..
Infrared Flow Measurement Technology of VCEM5100
The The VCEM5100 operates based on the principle of using two infrared detectors to measure flue gas flow without direct contact with the gas stream. This enables:
-
Minimized maintenance costs.
-
Stable operation at high temperatures up to 1000°C.
-
Ensured accuracy in harsh environments.
This makes it an ideal choice for automated emissions monitoring systems in thermal power plants, cement factories, and chemical plants.
Outstanding Advantages of the VCEM5100 Flue Gas Flow Measurement Device
- Non-contact measurement with hot, dusty, and highly corrosive gas streams.
- Direct measurement of high-velocity air flowDirect measurement of high-velocity gas flows.
- Capable of operating at gas temperatures up to 1000°C.oC
- Equipped with full capabilities for automatic calibration and range checking from low to high.
- Certified by TÜV Rheinland and MCERTs.
The VCEM5100 is a standalone device that can be easily integrated into the SmartCEM emissions monitoring system. It includes a data display unit for internal data verification.
The VCEM5000 is a continuous flue gas flow measurement device specifically designed for use within CODEL’s SmartCEM systems, where all measurements and analyses are managed through a Station Control Unit (SCU). This allows data export to the SmartCEM CODEL system for real-time data display, logging of measurement and analysis data, and generating reports in compliance with regulations.
Operating Principle of VCEM5100 Flue Gas Flow Measurement
The VCEM 5000/5100 employs a method similar to flow measurement using tracer dyes or radioactive markers. The velocity is determined by measuring the transit time of markers between two points, with the distance between these points known. Instead of injecting tracer particles, the device utilizes the natural turbulence of the gas stream as the marker.
Turbulence in the gas stream causes fluctuations in the infrared radiation emitted by the gas. This process is continuously variable and monitored by two infrared sensors positioned 1 meter apart along the direction of the gas flow. An electronic cross-correlation device is used to continuously compare the two sensor signals, determining the time delay between the two measurement points, thereby calculating the gas flow velocity.
Technical Specifications of VCEM5100
| Operating Principle | Utilizes infrared technology for measurement. |
| Measurement Unit | Gas flow rate (m³/s). |
| Ambient Temperature | Operates effectively in the range of -20°C to +50°C. |
|
Power Supply
|
48V DC, sourced from the Signal Processing Unit (SPU). |
| Construction Material | Aluminum with epoxy coating, IP67-rated for water and dust resistance. |
| Analog Output Signals |
|
| Logic Output Signals |
|
| Data Connectivity | Supports RS485 MODBUS protocol (optional). |
Applications of Flue Gas Flow Measurement Devices in Industry
CODEL flue gas flow measurement devices are widely applied across various industries, including:
-
Thermal Power Plants:Measuring flue gas flow from boilers.
-
Cement Industry:Monitoring emissions during production processes.
-
Waste Treatment:Ensuring compliance with environmental regulations.
-
Chemical Industry:Controlling the flow of hazardous gas emissions.
The VCEM5100 effectively meets the needs of businesses requiring modern and reliable environmental monitoring equipment.
Images of the VCEM5100 Flue Gas Flow Measurement Device
Optimizing Emissions Monitoring with Viet An Enviro
Viet An Enviro is proud to be the official distributor of CODEL flue gas flow measurement devices in Vietnam. We provide comprehensive solutions, from consultation and installation to maintenance, helping businesses comply with current environmental regulations.
Contact Viet An Enviro today for detailed quotations and consultation on để nhận báo giá và tư vấn chi tiết về the VCEM 5100 flow measurement device!!
Frequently Asked Questions (FAQ)
What is a flue gas flow measurement device?
This is a device used to measure the velocity and flow rate of flue gas emitted from industrial sources, aiding in air pollution monitoring and control.
What temperatures can the VCEM 5000/5100 operate in?
The device operates reliably at temperatures up to 1000°C, suitable for harsh environments.
How to choose the right flow measurement device?
Contact Viet An Enviro for tailored consultation based on your plant’s specific needs.
Why choose a non-contact flow measurement device?
Non-contact devices reduce maintenance costs and enhance durability, especially in corrosive flue gas environments.
