As plant requirements become increasingly stringent, the selection of flow measurement devices demands accuracy and cost-effectiveness. Measuring water inflow using noninvasive ultrasonic clamp-on technology addresses this challenge by measuring flow from outside the pipe without interfering with the existing pipeline.
Non-Invasive Ultrasonic Clamp-On Technology: An Advanced Solution for Water Inflow Measurement
Non-invasive ultrasonic clamp-on technology is a modern solution for measuring the flow rate of liquids in pipelines without the need to penetrate the pipe structure. Instead of cutting or modifying the pipeline, this technology uses externally mounted ultrasonic sensors to perform flow measurements.
A standout feature of non-invasive ultrasonic flow meters compared to other products on the market is their ability to diagnose the quality of the signal transmission/reception between the electrodes. This helps determine the optimal installation location when installation conditions are not ideal (10D upstream and 5D downstream of the device), and also allows for the input of the C factor in cases of old, aged pipelines.
Non-invasive clamp-on pipe flow meters come in two main types: portable and fixed installation. They are handy for quickly measuring water flow or checking the accuracy and stability of installed meters, thereby saving time, labor, and costs. The device is also easy to install and operate.
Ultrasonic sensors emit waves through the pipe wall and measure the time it takes for the waves to travel from the transmitter to the receiver. From this data, the device calculates the flow rate of the liquid inside the pipe with high accuracy. This technology is particularly effective for power plants, thermal power plants, hydroelectric power plants, and water supply systems, where pipelines are large and already complete. With the advantages of easy installation and no interruption to operations, non-invasive ultrasonic clamp-on technology helps maintain continuous system performance without the need to change the existing structure.
Introducing the FLUXUS F532WD Water Inflow Meter from Flexim – Emerson
In power plants such as thermal power plants, hydroelectric power plants, or water supply systems, the pipeline infrastructure is often complete with large diameters. Installing in-line flow meters, which require penetration of the pipeline, is very costly.
Flexim offers a solution for measuring water inflow using non-invasive clamp-on technology based on the ultrasonic wave principle, allowing for accurate measurement of flow without interfering with existing pipelines, old or aged pipelines, with the following benefits:
- No need to cut the pipe: Measures flow from outside the pipe, does not interfere with the pipe structure, reduces costs, and avoids interrupting production or exploitation operations.
- Saves installation time: The device is installed quickly in about 5-10 minutes thanks to pre-assembled mounting accessories and a magnet.
- Maintains continuous operation: Installation does not affect system operation, maintaining continuous production efficiency.
- Có khả năng đo trên nhiều loại vật liệu ống khác nhau, tích hợp thiết bị đo độ dày thành ống và bộ nhớ lưu trữ dữ liệu lên đến 100.000 giá trị.
- Wide measurement range, suitable for pipe diameters from DN6 to DN6500.
Main Components of the FLUXUS F532WD Flow Meter
- Display device (transmitter).
- Transducers
- Accessories: Connectors and extension cables
The FLUXUS F532WD is an ideal solution for power plants, thermal power plants, hydroelectric power plants, and water supply systems, thanks to its accurate and cost-effective water inflow measurement capabilities. With its superior features, Flexim's device ensures high operational efficiency and maintains continuous production processes
Why should you choose Viet An Enviro for industrial monitoring and measurement equipment?
Viet An Enviro is Vietnam's leading provider of environmental monitoring and industrial measurement equipment. With over 1000 monitoring stations nationwide and 14 years of experience serving 1500 organizations and businesses, we are committed to:
- High-quality equipment: 100% genuine imported from EU/G7 countries, with full CO&CQ certificates.
- Comprehensive services: Official warranty, user manuals, and operation instructions.
- Our professional service team is always ready to support customers throughout the entire process, ensuring equipment operates reliably and accurately.
Our team at Viet An is here to provide personalized advice and technical support for your environmental monitoring and industrial measurement needs. We're committed to helping you optimize your investment.
