The DCEM2100 continuous emission dust monitoring device from CODEL

In the context of increasingly stringent environmental regulations in Vietnam, the use of high-quality emission monitoring equipment is a critical factor in helping businesses comply with legal requirements and protect the environment.

The DCEM2100 continuous emission dust monitoring from CODEL (United Kingdom),distributed by Viet An Enviro,is an optimal solution for industries such as cement, thermal power, steel, chemicals, and waste treatment.

Khí thải xử lý không đạt chuẩn sẽ gây ô nhiễm
Air pollution frequently occurs in areas near industrial zones.

Overview of the DCEM2100 Continuous Emission Dust Monitoring Device

The DCEM2100 is the latest generation in range of emission monitoring equipment , designed for continuous measurement of opacity and dust concentration results in industrial exhaust gases. It is an advanced CEMS (Continuous Emission Monitoring System) that meets Vietnam’s environmental monitoring: requirements and complies with QAL1 standards.
thiet-bi-do-bui-khi-thai-lien-tuc-dust-monitor-codel-anh-quoc
The DCEM2100 employs dual-pass optical transmission technology, continuously measuring the light transmission through a stack or exhaust duct. This system provides accurate average dust concentration results and detects deviations caused by stack movement.

2. Operating Principle

The device operates based on the principle of measuring light attenuation as it passes through the exhaust gas stream. Utilizing dual-pass transmissometer technology, light is transmitted twice through the same section of the gas stream, enhancing accuracy and minimizing errors due to exhaust gas movement.

thiet-bi-do-bui-khi-thai-lien-tuc-dust-monitor-codel-anh-quoc

Key Features of the DCEM2100 Continuous Emission Dust Monitoring Device

  • Operating Principle: Dual-pass optical, open-path transmissometer.
  • Components: Two Transceiver Units with 10m cable.
  • Signal Processing: Signal Processor Unit, 2 Air Purges, flange connection to stack.
  • Measurement Units: % opacity, mg/m³, mg/Nm³.
  • Light Source: Modulated high-intensity LED at 637nm (or 580nm) wavelength.
  • Signal Receiver: Continuous measurement with infrared transmitter and receiver.
  • Measurement Range: 0 ~ 500 mg/Nm³.
  • Optical Path Length: 0.5 ~ 15m.
  • Accuracy: ±0.2% opacity.
  • Response Time: 10 seconds.
  • Calibration: Integrated auto-zero and auto-span compliant with US EPA standards.
  • Stack Temperature: Up to 850°C.
  • Sensor Body: Epoxy-coated aluminum with IP66 protection rating.
  • Cleaning Mechanism: Compressed air, 1 liter/sec at maximum 4 bar.
  • Control Connection: Interfaces with control cabinet item No. 1.
  • Manufacturer/Origin: CODEL – United Kingdom.

thiet-bi-do-bui-khi-thai-lien-tuc-dust-monitor-codel-anh-quoc

Why Choose CODEL Emission Dust Monitoring Equipment?

The DCEM2100 continuous emission dust monitoring device utilizes Dual-pass transmissometer technology,delivering high accuracy in measuring opacity (% opacity) and dust concentration (mg/Nm³). Below are its outstanding advantages:

  • High accuracy: Dual-pass optical technology ensures precise measurements even under fluctuating exhaust gas conditions.
  • Superior Durability:: Epoxy-coated aluminum housing, corrosion-resistant, with IP66 protection rating.
  • Easy Maintenance:Automatic cleaning mechanism using compressed air (1 liter/sec @ 4 bar) minimizes maintenance efforts.
  • CEMS Integration:Seamlessly integrates with Continuous Emission Monitoring Systems (CEMS) for continuous monitoring.
  • Regulatory Compliance:Meets Circular 10/2021/TT-BTNMT and Vietnam’s environmental standards.

thiet-bi-do-bui-khi-thai-lien-tuc-dust-monitor-codel-anh-quoc

5. Practical Applications

The DCEM2100 is an ideal choice for industries such as thermal power, cement, steel, chemicals, and plants with large emission systems. This device helps businesses comply with environmental protection regulations under Decree 40/2019/ND-CP and Circular 10/2021/TT-BTNMT of Vietnam.
  • Thermal Power Plants:Monitors dust in combustion exhaust gases.
  • Cement Plants:Ensures compliance with emission standards.
  • Industrial Waste Incinerators:Tracks and controls dust concentration.
  • Metallurgy & Steel Production:Assesses dust pollution levels during manufacturing processes

thiet-bi-do-luu-luong-khi-thai-vcem5100

6. Where to Purchase the DCEM2100 Continuous Emission Dust Monitoring Device Reliably?

Việt An Enviro is proud to be the official distributor of CODEL emission dust monitoring equipment in Vietnam. With over 10 years of experience in environmental monitoring:, we offer:

  • The DCEM2100 continuous emission dust monitoring device from CODEL, meeting international standards.
  • Professional Services installation, maintenance, and calibration services.
  • Free Technical Consultation: Support for compliance with legal regulations.

Contact us today for the best emission monitoring solutions:

  • Hotline: +84 901 379 116 (Sales) | +84 901 888 499 (Service)
  • Email: sales@vietan-enviro.com

————————————————————————————

Head Office

  • Address: 4E Street No. 6, An Phu Ward, Thu Duc City, Ho Chi Minh City.
  • (Sales) +84 901 379 116 | (Service) +84 901 888 499

Northern Viet An

  • Address: Lot 33, BT4-1 area, Trung Van residential project, Trung Van Ward, Nam Tu Liem District, Hanoi.
  • (Sales) +84 901 851 116 | (Service) +84 901 888 499

Central Viet An

  • Address: 5A Mai Xuan Thuong Street, Hoa Khe Ward, Thanh Khe District, Da Nang City.
  • (Sales) +84 898 119 116 | (Service) +84 901 888 499

Frequently Asked Questions (FAQ)

  1. What is emission monitoring?
    Emission monitoring is the process of continuously measuring and monitoring components in industrial exhaust gases, such as dust, opacity, and other pollutants.
  2. What is the role of CEMS in environmental monitoring?
    CEMS (Continuous Emission Monitoring Systems) enable businesses to track and report emission data in real-time, ensuring compliance with legal regulations.
  3. Is the DCEM2100 suitable for thermal power plants?
    Yes, the DCEM2100 is designed for thermal power plants, cement plants, steel plants, and other heavy industries.
  4. How to choose the best emission monitoring equipment?
    Select equipment that is QAL1 certified, highly durable, easy to maintain, and suitable for Vietnam’s environmental conditions.
